ESPECIFICACIONES TÉCNICAS
Country of origin | Made in Laos |
---|---|
UPC number | (ABB) 197497110562 (ABU) 197497188141 |
Color | Black |
Dimensions (W x D x H) | 769.5 x 115.2 x 103 mm |
Weight | 2.54 kg |
Package weight | 300 g |
Master carton dimension (metric) | 24.5 x 44 x 29.5 cm |
Pallet dimensions (W x D x H) | 101.6 x 121.9 x 149 cm |
Multiple order quantity | 1 |
Products per pallet layer | 40 |
Pallet (layers) | 7 |
Products per pallet | 280 |
Cartons per pallet | 28 |
Cartons per layer | 4 |
Master carton weight (metric) | 5.25 kg |
Pallet weight | 357 kg |
Power supply type | External Auto sensing |
Camera resolution | 2160p, 4K UHD (3840 x 2160) |
Video frame rate | 5–60 fps (up to 4K resolution at 15 fps in call) |
Total camera resolution (megapixels) | 20 MP |
Zoom capability | 5x digital |
Lens cover capabilites | Attachable |
Smart camera technology | People framing Group framing DirectorAI perimeter Speaker framing |
Diagonal field of view (dFoV) | 110° |
Camera type | Single-lens |
People video resolution | 4K, 30 fps (TX and RX) from 2048 Kbps 1080p, 60 fps from 1740 Kbps 1080p, 30 fps from 1024 Kbps 720p, 60 fps from 832 Kbps 720p, 30 fps from 512 Kbps |
Content video resolution (input) | UHD (3840 x 2160) HD (1920 x 1080) WSXGA+ (1680 x 1050) UXGA (1600 x 1200) SXGA (1280 x 1024) WXGA (1280 x 768) HD (1280 x 720) XGA (1024 x 768) SVGA (800 x 600) |
Content video resolution (output) | UHD (3840 x 2160) HD (1920 x 1080) WSXGA+ (1680 x 1050) SXGA+ (1400 x 1050) SXGA (1280 x 1024) HD (1280 x 720) XGA (1024 x 768) |
Horizontal field of view (hFoV) | 95° |
Camera range (metric) | Up to 6.1 m |
Video standards | H.264 AVC H.264 High Profile H.265 H.239 |
Audio standards | 22 kHz with Polycom Siren 22 technology 20 kHz with G.719 (M- Mode) and Polycom Siren 22 technology 14 kHz with Polycom Siren 14 technology, G.722.1 Annex C 7 kHz with G.722, G.722.1 3.4 kHz with G.711, G.728, G.729A |
Digital signage | Appspace Raydiant |
Wireless technologies | Bluetooth® 5.0 Wi-Fi 802.11a/b/g/n/ac/ax (MIMO) Multi-channel Concurrency1 |
Network capabilities | IPv4 IPv6 1x 10/100/1G Ethernet Auto-MDIX H.323 and/or SIP up to 6 Mbps in Poly App video mode Polycom Lost Packet Recovery (LPR) technology Dynamic bandwidth allocation Reconfigurable MTU size Web proxy support: basic, digest, and NTLM Simple Certificate Enrollment Protocol (SCEP) |
Operating altitude | 4,877 m |
Operating humidity range | 15 to 80% |
Non-Operating Humidity Range | 5 to 95% |
Operating temperature range | 0 to 40 °C |
Non-operating temperature – Celsius | -40 to 70 °C |
Microphone type | Two MEMS microphones Two second-order microphones |
Sensitivity (speaker) | 79 dB |
Audio | Full duplex audio Acoustic echo cancellation Poly NoiseBlockAI technology Poly Acoustic Fence technology |
Speaker type | Dual speakers |
Speaker output power | 2 x 20 W (RMS) |
Microphone pickup range (metric) | Up to 6.09 m |
Physical security | Standard Kensington lock slot |
Security management | AES 128 bits encryption AES 256 bits encryption H.235.6 support Authenticated access to admin menus, web interface, and APIs Local account password policy configuration Security profiles Local account and login port lockout Secure defaults Remote logging with support for TLS Active directory external authentication Binary Floor Control Protocol (BFCP) |
Certified collaboration software | Zoom Microsoft Teams Google Meet |
Management Software | Poly Lens |
Interoperability | All cloud service providers through Poly Video App mode USB Device mode Support for native 3rd party applications including Zoom, Microsoft Teams, Dialpad, GoToRoom, RingCentral and StarLeaf |
Ports | 1 HDMI-in 2.0 (video and audio) 2 HDMI-out 2.0 (video) 1 USB Type-C® 5Gbps signaling rate 2 USB Type-A 5Gbps signaling rate 1 RJ-45 1 line in (optional microphone) |
